Details

An R6 class representing a single image, backed by an OpenCV cv::Mat (CPU) or cv::UMat (GPU).

Active bindings

nrow

Number of rows (height in pixels).

ncol

Number of columns (width in pixels).

nchan

Number of channels.

depth

Bit depth code (0=CV_8U, 1=CV_8S, 2=CV_16U, ...).

depth_name

Human-readable depth string (e.g. "CV_8U").

gpu

Logical; TRUE if the image is currently on the GPU.

colorspace

Character string describing the color space (e.g. "BGR", "GRAY").

Methods

Public methods

• Image$new()

• Image$to_array()

• Image$to_native_raster()

• Image$plot()

• Image$write()

• Image$to_gpu()

• Image$to_cpu()

• Image$copy()

• Image$convert_color()

• Image$convert_color_()

• Image$convert_depth()

• Image$convert_depth_()

• Image$to_gray()

• Image$to_gray_()

• Image$to_bgr()

• Image$to_bgr_()

• Image$to_hsv()

• Image$to_hsv_()

• Image$to_lab()

• Image$to_lab_()

• Image$mean()

• Image$min()

• Image$max()

• Image$sd()

• Image$var()

• Image$sum()

• Image$median()

• Image$quantile()

• Image$add()

• Image$add_()

• Image$subtract()

• Image$subtract_()

• Image$multiply()

• Image$multiply_()

• Image$divide()

• Image$divide_()

• Image$absdiff()

• Image$absdiff_()

• Image$add_weighted()

• Image$add_weighted_()

• Image$bitwise_and()

• Image$bitwise_and_()

• Image$bitwise_or()

• Image$bitwise_or_()

• Image$bitwise_xor()

• Image$bitwise_xor_()

• Image$bitwise_not()

• Image$bitwise_not_()

• Image$blur()

• Image$blur_()

• Image$gaussian_blur()

• Image$gaussian_blur_()

• Image$median_blur()

• Image$median_blur_()

• Image$bilateral_filter()

• Image$bilateral_filter_()

• Image$sobel()

• Image$sobel_()

• Image$laplacian()

• Image$laplacian_()

• Image$canny()

• Image$canny_()

• Image$scharr()

• Image$scharr_()

• Image$filter2D()

• Image$filter2D_()

• Image$sep_filter2D()

• Image$sep_filter2D_()

• Image$morph()

• Image$morph_()

• Image$resize()

• Image$resize_()

• Image$rotate()

• Image$rotate_()

• Image$flip()

• Image$flip_()

• Image$crop()

• Image$crop_()

• Image$warp_affine()

• Image$warp_affine_()

• Image$warp_perspective()

• Image$warp_perspective_()

• Image$border()

• Image$border_()

• Image$tile()

• Image$tile_()

• Image$set_to()

• Image$set_to_()

• Image$threshold()

• Image$threshold_()

• Image$adaptive_threshold()

• Image$adaptive_threshold_()

• Image$in_range()

• Image$in_range_()

• Image$draw_line()

• Image$draw_line_()

• Image$draw_arrow()

• Image$draw_arrow_()

• Image$draw_rectangle()

• Image$draw_rectangle_()

• Image$draw_circle()

• Image$draw_circle_()

• Image$draw_ellipse()

• Image$draw_ellipse_()

• Image$draw_arc()

• Image$draw_arc_()

• Image$draw_polyline()

• Image$draw_polyline_()

• Image$fill_poly()

• Image$fill_poly_()

• Image$draw_text()

• Image$draw_text_()

• Image$hist()

• Image$hist_eq()

• Image$hist_eq_()

• Image$hist_match()

• Image$hist_match_()

• Image$CLAHE()

• Image$CLAHE_()

• Image$minmax_loc()

• Image$count_nonzero()

• Image$find_nonzero()

• Image$pow()

• Image$pow_()

• Image$exp()

• Image$exp_()

• Image$log()

• Image$log_()

• Image$sqrt()

• Image$sqrt_()

• Image$extract_channel()

• Image$insert_channel()

• Image$insert_channel_()

• Image$LUT()

• Image$LUT_()

• Image$print()

---

Method new()

Create a new Image.

Usage

Image$new(x, colorspace = "BGR", depth = NULL)

Arguments

x

A file path (character), a 3D array (nrow x ncol x nchan), or a 2D matrix. Use an integer array for integer depths (CV_8U, CV_16U, CV_16S) and a double array for float depths (CV_32F, CV_64F).

colorspace

Color space label string. Ignored when reading from file (OpenCV assumes BGR for color images).

depth

Character. Bit depth of the image. One of "CV_8U", "CV_16U", "CV_16S", "CV_32F", "CV_64F". If NULL (default), inferred from the array type: integer arrays default to "CV_8U", double arrays to "CV_32F", and a message is emitted. Ignored when x is a file path or external pointer.

---

Method to_array()

Convert the image to an array (nrow x ncol x nchan). Returns an integer array for CV_8U, CV_16U, and CV_16S images; a double array for CV_32F and CV_64F images.

Usage

Image$to_array()

Returns

An array with dimensions [nrow, ncol, nchan].

---

Method to_native_raster()

Convert the image to a nativeRaster object.

Usage

Image$to_native_raster()

Returns

A nativeRaster matrix suitable for use with grid or other graphics systems.

---

Method plot()

Display the image using R's graphics device.

Usage

Image$plot(newpage = TRUE, ...)

Arguments

newpage

Logical. If TRUE (default), clears the graphics device before drawing. Set to FALSE when composing multiple images in a layout using grid viewports.

...

Additional arguments passed to grid::grid.raster().

Returns

self invisibly.

---

Method write()

Write the image to a file. Format is inferred from the file extension.

Usage

Image$write(path)

Arguments

path

Character. Output file path (e.g. "output.png", "output.jpg").

Returns

self invisibly.

---

Method to_gpu()

Upload the image to GPU memory (cv::UMat). No-op if already on GPU.

Usage

Image$to_gpu()

Returns

self invisibly.

---

Method to_cpu()

Download the image from GPU to CPU memory (cv::Mat). No-op if already on CPU.

Usage

Image$to_cpu()

Returns

self invisibly.

---

Method copy()

Create a deep copy of this image.

Usage

Image$copy()

Returns

A new Image with independent C++ storage.

---

Method convert_color()

Convert to a new color space. Returns a new Image.

Usage

Image$convert_color(to)

Arguments

to

Character. Target color space (e.g. "GRAY", "HSV").

Returns

A new Image.

---

Method convert_color_()

Convert to a new color space in place.

Usage

Image$convert_color_(to)

Arguments

to

Character. Target color space.

Returns

self invisibly.

---

Method convert_depth()

Convert to a new bit depth. Returns a new Image. Values are cast directly with no scaling: a CV_8U pixel with value 100 becomes 100.0 in CV_32F, not 0.392. Use convert_depth followed by arithmetic if you need normalized floating-point values.

Usage

Image$convert_depth(to)

Arguments

to

Character. Target depth, one of "CV_8U", "CV_16U", "CV_16S", "CV_32F", "CV_64F".

Returns

A new Image.

---

Method convert_depth_()

Convert to a new bit depth in place. Values are cast directly with no scaling (see convert_depth).

Usage

Image$convert_depth_(to)

Arguments

to

Character. Target depth, one of "CV_8U", "CV_16U", "CV_16S", "CV_32F", "CV_64F".

Returns

self invisibly.

---

Method to_gray()

Convert to grayscale. Returns a new Image.

Usage

Image$to_gray()

Returns

A new Image with colorspace "GRAY".

---

Method to_gray_()

Convert to grayscale in place.

Usage

Image$to_gray_()

Returns

self invisibly.

---

Method to_bgr()

Convert to BGR. Returns a new Image.

Usage

Image$to_bgr()

Returns

A new Image with colorspace "BGR".

---

Method to_bgr_()

Convert to BGR in place.

Usage

Image$to_bgr_()

Returns

self invisibly.

---

Method to_hsv()

Convert to HSV. Returns a new Image.

Usage

Image$to_hsv()

Returns

A new Image with colorspace "HSV".

---

Method to_hsv_()

Convert to HSV in place.

Usage

Image$to_hsv_()

Returns

self invisibly.

---

Method to_lab()

Convert to LAB color space. Returns a new Image.

Usage

Image$to_lab()

Returns

A new Image with colorspace "LAB".

---

Method to_lab_()

Convert to LAB color space in place.

Usage

Image$to_lab_()

Returns

self invisibly.

---

Method mean()

Per-channel mean pixel value.

Usage

Image$mean()

Returns

Named numeric vector of length nchan.

---

Method min()

Per-channel minimum pixel value.

Usage

Image$min()

Returns

Named numeric vector of length nchan.

---

Method max()

Per-channel maximum pixel value.

Usage

Image$max()

Returns

Named numeric vector of length nchan.

---

Method sd()

Per-channel standard deviation (population).

Usage

Image$sd()

Returns

Named numeric vector of length nchan.

---

Method var()

Per-channel variance (population).

Usage

Image$var()

Returns

Named numeric vector of length nchan.

---

Method sum()

Per-channel pixel sum.

Usage

Image$sum()

Returns

Named numeric vector of length nchan.

---

Method median()

Per-channel median pixel value.

Usage

Image$median()

Returns

Named numeric vector of length nchan.

---

Method quantile()

Per-channel quantiles.

Usage

Image$quantile(probs = 0.5)

Arguments

probs

Numeric vector of probabilities in [0, 1]. Defaults to 0.5 (median).

Returns

A matrix with length(probs) rows and nchan columns. Row names are percentages (e.g. "25%"); column names are channel names.

---

Method add()

Add another image or a scalar to this image.

Usage

Image$add(other, mask = NULL)

Arguments

other

An Image or a numeric vector (length 1 or nchan).

mask

Optional single-channel CV_8U Image mask. Only pixels where mask is non-zero are updated; others retain self's values.

Returns

A new Image.

---

Method add_()

Add in place.

Usage

Image$add_(other, mask = NULL)

Arguments

other

An Image or a numeric vector (length 1 or nchan).

mask

Optional single-channel CV_8U Image mask.

Returns

self invisibly.

---

Method subtract()

Subtract another image or a scalar from this image.

Usage

Image$subtract(other, mask = NULL)

Arguments

other

An Image or a numeric vector (length 1 or nchan).

mask

Optional single-channel CV_8U Image mask.

Returns

A new Image.

---

Method subtract_()

Subtract in place.

Usage

Image$subtract_(other, mask = NULL)

Arguments

other

An Image or a numeric vector (length 1 or nchan).

mask

Optional single-channel CV_8U Image mask.

Returns

self invisibly.

---

Method multiply()

Multiply this image element-wise by another image or a scalar.

Usage

Image$multiply(other, mask = NULL)

Arguments

other

An Image or a numeric vector (length 1 or nchan).

mask

Optional single-channel CV_8U Image mask.

Returns

A new Image.

---

Method multiply_()

Multiply in place.

Usage

Image$multiply_(other, mask = NULL)

Arguments

other

An Image or a numeric vector (length 1 or nchan).

mask

Optional single-channel CV_8U Image mask.

Returns

self invisibly.

---

Method divide()

Divide this image element-wise by another image or a scalar.

Usage

Image$divide(other, mask = NULL)

Arguments

other

An Image or a numeric vector (length 1 or nchan).

mask

Optional single-channel CV_8U Image mask.

Returns

A new Image.

---

Method divide_()

Divide in place.

Usage

Image$divide_(other, mask = NULL)

Arguments

other

An Image or a numeric vector (length 1 or nchan).

mask

Optional single-channel CV_8U Image mask.

Returns

self invisibly.

---

Method absdiff()

Compute the absolute difference with another image or a scalar.

Usage

Image$absdiff(other, mask = NULL)

Arguments

other

An Image or a numeric vector (length 1 or nchan).

mask

Optional single-channel CV_8U Image mask.

Returns

A new Image.

---

Method absdiff_()

Absolute difference in place.

Usage

Image$absdiff_(other, mask = NULL)

Arguments

other

An Image or a numeric vector (length 1 or nchan).

mask

Optional single-channel CV_8U Image mask.

Returns

self invisibly.

---

Method add_weighted()

Weighted addition of two images: w1*self + w2*other + gamma.

Usage

Image$add_weighted(other, w1, w2, gamma = 0, mask = NULL)

Arguments

other

An Image.

w1

Numeric scalar. Weight for this image.

w2

Numeric scalar. Weight for other.

gamma

Numeric scalar. Brightness offset added after blending. Default 0.

mask

Optional single-channel CV_8U Image mask.

Returns

A new Image.

---

Method add_weighted_()

Weighted addition in place.

Usage

Image$add_weighted_(other, w1, w2, gamma = 0, mask = NULL)

Arguments

other

An Image.

w1

Numeric scalar. Weight for this image.

w2

Numeric scalar. Weight for other.

gamma

Numeric scalar. Brightness offset. Default 0.

mask

Optional single-channel CV_8U Image mask.

Returns

self invisibly.

---

Method bitwise_and()

Bitwise AND with another image or a scalar.

Usage

Image$bitwise_and(other, mask = NULL)

Arguments

other

An Image or a numeric vector (length 1 or nchan).

mask

Optional single-channel CV_8U Image mask.

Returns

A new Image.

---

Method bitwise_and_()

Bitwise AND in place.

Usage

Image$bitwise_and_(other, mask = NULL)

Arguments

other

An Image or a numeric vector (length 1 or nchan).

mask

Optional single-channel CV_8U Image mask.

Returns

self invisibly.

---

Method bitwise_or()

Bitwise OR with another image or a scalar.

Usage

Image$bitwise_or(other, mask = NULL)

Arguments

other

An Image or a numeric vector (length 1 or nchan).

mask

Optional single-channel CV_8U Image mask.

Returns

A new Image.

---

Method bitwise_or_()

Bitwise OR in place.

Usage

Image$bitwise_or_(other, mask = NULL)

Arguments

other

An Image or a numeric vector (length 1 or nchan).

mask

Optional single-channel CV_8U Image mask.

Returns

self invisibly.

---

Method bitwise_xor()

Bitwise XOR with another image or a scalar.

Usage

Image$bitwise_xor(other, mask = NULL)

Arguments

other

An Image or a numeric vector (length 1 or nchan).

mask

Optional single-channel CV_8U Image mask.

Returns

A new Image.

---

Method bitwise_xor_()

Bitwise XOR in place.

Usage

Image$bitwise_xor_(other, mask = NULL)

Arguments

other

An Image or a numeric vector (length 1 or nchan).

mask

Optional single-channel CV_8U Image mask.

Returns

self invisibly.

---

Method bitwise_not()

Bitwise NOT (invert all bits).

Usage

Image$bitwise_not(mask = NULL)

Arguments

mask

Optional single-channel CV_8U Image mask.

Returns

A new Image.

---

Method bitwise_not_()

Bitwise NOT in place.

Usage

Image$bitwise_not_(mask = NULL)

Arguments

mask

Optional single-channel CV_8U Image mask.

Returns

self invisibly.

---

Method blur()

Apply a normalised box filter (simple average blur).

Usage

Image$blur(ksize)

Arguments

ksize

Length-2 integer vector c(width, height) of positive integers specifying the kernel size.

Returns

A new Image.

---

Method blur_()

Box blur in place.

Usage

Image$blur_(ksize)

Arguments

ksize

Length-2 integer vector c(width, height) of positive integers specifying the kernel size.

Returns

self invisibly.

---

Method gaussian_blur()

Apply a Gaussian blur.

Usage

Image$gaussian_blur(ksize, sigma)

Arguments

ksize

Length-2 vector. Each element must be a positive odd integer or 0. When 0, the kernel size is inferred from sigma automatically.

sigma

Length-1 or length-2 positive numeric. Gaussian standard deviation in the X (and optionally Y) direction. A single value is applied to both axes.

Returns

A new Image.

---

Method gaussian_blur_()

Gaussian blur in place.

Usage

Image$gaussian_blur_(ksize, sigma)

Arguments

ksize

Length-2 vector. Each element must be a positive odd integer or 0. When 0, the kernel size is inferred from sigma automatically.

sigma

Length-1 or length-2 positive numeric. A single value is applied to both axes.

Returns

self invisibly.

---

Method median_blur()

Apply a median blur.

Usage

Image$median_blur(ksize)

Arguments

ksize

Single positive odd integer. The kernel is always square (OpenCV constraint).

Returns

A new Image.

---

Method median_blur_()

Median blur in place.

Usage

Image$median_blur_(ksize)

Arguments

ksize

Single positive odd integer. The kernel is always square (OpenCV constraint).

Returns

self invisibly.

---

Method bilateral_filter()

Apply a bilateral filter (edge-preserving smoothing).

Usage

Image$bilateral_filter(d, sigma_color, sigma_space)

Arguments

d

Single integer. Diameter of the pixel neighbourhood. When d <= 0, the diameter is computed from sigma_space.

sigma_color

Single positive numeric. Filter sigma in colour space.

sigma_space

Single positive numeric. Filter sigma in coordinate space.

Returns

A new Image.

---

Method bilateral_filter_()

Bilateral filter in place.

Usage

Image$bilateral_filter_(d, sigma_color, sigma_space)

Arguments

d

Single integer. Diameter of the pixel neighbourhood. When d <= 0, the diameter is computed from sigma_space.

sigma_color

Single positive numeric. Filter sigma in colour space.

sigma_space

Single positive numeric. Filter sigma in coordinate space.

Returns

self invisibly.

---

Method sobel()

Apply the Sobel operator to compute image gradients. Returns a new Image.

Usage

Image$sobel(
  dx,
  dy,
  ksize = 3,
  ddepth = NULL,
  scale = 1,
  delta = 0,
  border_type = "reflect_101"
)

Arguments

dx

Non-negative integer. Order of x derivative.

dy

Non-negative integer. Order of y derivative. dx + dy must be >= 1.

ksize

Integer. Sobel kernel aperture size: 1, 3, 5, or 7. The limit of 7 is an OpenCV requirement.

ddepth

Character. Output depth: "CV_16S", "CV_32F", or "CV_64F". Default NULL (depth inferred from input; a message is emitted).

scale

Single positive numeric. Optional scale factor for the computed derivatives. Must be positive (use convert_depth + arithmetic to invert gradient sign). Default 1.

delta

Single numeric. Optional delta added to results before storing. Default 0.

border_type

Character. How to fill pixels outside the image boundary. "reflect_101" (default) mirrors the image excluding the edge pixel (e.g. dcb|abcde|dcb); "reflect" mirrors including the edge pixel (e.g. edcb|abcde|edcb); "replicate" repeats the nearest edge pixel; "constant" fills with a fixed value (0, i.e. black). "wrap" is not supported by OpenCV for these operations.

Returns

A new Image.

Examples

\donttest{
img_path <- system.file("img", "brick_wall.jpg", package = "Retina")
img <- Image$new(img_path)
grad_x <- img$sobel(1, 0)
grad_x$plot()
}

---

Method sobel_()

Sobel operator in place.

Usage

Image$sobel_(
  dx,
  dy,
  ksize = 3,
  ddepth = NULL,
  scale = 1,
  delta = 0,
  border_type = "reflect_101"
)

Arguments

dx

Non-negative integer. Order of x derivative.

dy

Non-negative integer. Order of y derivative. dx + dy must be >= 1.

ksize

Integer. Sobel kernel aperture size: 1, 3, 5, or 7.

ddepth

Character. Output depth: "CV_16S", "CV_32F", or "CV_64F". Default NULL (depth inferred from input; a message is emitted).

scale

Single positive numeric. Optional scale factor for the computed derivatives. Must be positive (use convert_depth + arithmetic to invert gradient sign). Default 1.

delta

Single numeric. Delta added to results. Default 0.

border_type

Character. How to fill pixels outside the image boundary. "reflect_101" (default) mirrors the image excluding the edge pixel (e.g. dcb|abcde|dcb); "reflect" mirrors including the edge pixel (e.g. edcb|abcde|edcb); "replicate" repeats the nearest edge pixel; "constant" fills with a fixed value (0, i.e. black). "wrap" is not supported by OpenCV for these operations.

Returns

self invisibly.

Examples

\donttest{
img_path <- system.file("img", "brick_wall.jpg", package = "Retina")
img <- Image$new(img_path)
img$sobel_(1, 0)
img$plot()
}

---

Method laplacian()

Apply the Laplacian operator to detect edges. Returns a new Image.

Usage

Image$laplacian(
  ksize = 1,
  ddepth = NULL,
  scale = 1,
  delta = 0,
  border_type = "reflect_101"
)

Arguments

ksize

Integer. Aperture size for the Laplacian kernel: 1, 3, 5, or 7. ksize = 1 uses the 3-point central-difference stencil. Default 1.

ddepth

Character. Output depth: "CV_16S", "CV_32F", or "CV_64F". Default NULL (depth inferred from input; a message is emitted).

scale

Single positive numeric. Optional scale factor. Must be positive. Default 1.

delta

Single numeric. Optional delta added to results. Default 0.

border_type

Character. How to fill pixels outside the image boundary. "reflect_101" (default) mirrors the image excluding the edge pixel (e.g. dcb|abcde|dcb); "reflect" mirrors including the edge pixel (e.g. edcb|abcde|edcb); "replicate" repeats the nearest edge pixel; "constant" fills with a fixed value (0, i.e. black). "wrap" is not supported by OpenCV for these operations.

Returns

A new Image.

Examples

\donttest{
img_path <- system.file("img", "flower.jpg", package = "Retina")
img <- Image$new(img_path)
edges <- img$laplacian()
edges$plot()
}

---

Method laplacian_()

Laplacian operator in place.

Usage

Image$laplacian_(
  ksize = 1,
  ddepth = NULL,
  scale = 1,
  delta = 0,
  border_type = "reflect_101"
)

Arguments

ksize

Integer. Aperture size: 1, 3, 5, or 7. Default 1.

ddepth

Character. Output depth: "CV_16S", "CV_32F", or "CV_64F". Default NULL (depth inferred from input; a message is emitted).

scale

Single positive numeric. Optional scale factor. Must be positive. Default 1.

delta

Single numeric. Delta added to results. Default 0.

border_type

Character. How to fill pixels outside the image boundary. "reflect_101" (default) mirrors the image excluding the edge pixel (e.g. dcb|abcde|dcb); "reflect" mirrors including the edge pixel (e.g. edcb|abcde|edcb); "replicate" repeats the nearest edge pixel; "constant" fills with a fixed value (0, i.e. black). "wrap" is not supported by OpenCV for these operations.

Returns

self invisibly.

Examples

\donttest{
img_path <- system.file("img", "flower.jpg", package = "Retina")
img <- Image$new(img_path)
img$laplacian_()
img$plot()
}

---

Method canny()

Detect edges using the Canny algorithm. Returns a new single-channel CV_8U Image with pixel values 0 (no edge) or 255 (edge). Input must be a single-channel grayscale image.

Usage

Image$canny(
  low_threshold,
  high_threshold,
  aperture_size = 3,
  L2_gradient = FALSE
)

Arguments

low_threshold

Single non-negative numeric. Lower hysteresis threshold.

high_threshold

Single positive numeric. Upper hysteresis threshold. Must be >= low_threshold.

aperture_size

Integer. Size of the Sobel kernel used internally: 3, 5, or 7. Default 3.

L2_gradient

Logical scalar. If TRUE, use the L2 norm for gradient magnitude (more accurate but slower). Default FALSE.

Returns

A new Image.

Examples

\donttest{
img_path <- system.file("img", "staircase.jpg", package = "Retina")
img <- Image$new(img_path)$convert_color("GRAY")
edges <- img$canny(50, 150)
edges$plot()
}

---

Method canny_()

Canny edge detection in place.

Usage

Image$canny_(
  low_threshold,
  high_threshold,
  aperture_size = 3,
  L2_gradient = FALSE
)

Arguments

low_threshold

Single non-negative numeric. Lower hysteresis threshold.

high_threshold

Single positive numeric. Upper hysteresis threshold. Must be >= low_threshold.

aperture_size

Integer. Size of the Sobel kernel: 3, 5, or 7. Default 3.

L2_gradient

Logical scalar. Use L2 norm for gradient magnitude. Default FALSE.

Returns

self invisibly.

Examples

\donttest{
img_path <- system.file("img", "staircase.jpg", package = "Retina")
img <- Image$new(img_path)$convert_color("GRAY")
img$canny_(50, 150)
img$plot()
}

---

Method scharr()

Apply the Scharr operator to compute image gradients. Returns a new Image. Scharr uses a fixed 3x3 kernel with better rotational symmetry than Sobel. Exactly one of dx or dy must be 1.

Usage

Image$scharr(
  dx,
  dy,
  ddepth = NULL,
  scale = 1,
  delta = 0,
  border_type = "reflect_101"
)

Arguments

dx

Integer. Order of x derivative: 0 or 1.

dy

Integer. Order of y derivative: 0 or 1. Exactly one of dx, dy must be 1.

ddepth

Character or NULL. Output depth: "CV_16S", "CV_32F", or "CV_64F". When NULL (default), the output depth is inferred from the input depth and a message is emitted.

scale

Single positive numeric. Scale factor for computed derivatives. Default 1.

delta

Single numeric. Constant added to output pixels. Default 0.

border_type

Character. How to fill pixels outside the image boundary. "reflect_101" (default) mirrors the image excluding the edge pixel (e.g. dcb|abcde|dcb); "reflect" mirrors including the edge pixel (e.g. edcb|abcde|edcb); "replicate" repeats the nearest edge pixel; "constant" fills with a fixed value (0, i.e. black). "wrap" is not supported by OpenCV for Scharr.

Returns

A new Image.

Examples

\donttest{
img_path <- system.file("img", "brick_wall.jpg", package = "Retina")
img <- Image$new(img_path)
grad_x <- img$scharr(1, 0)
grad_x$plot()
}

---

Method scharr_()

Scharr operator in place.

Usage

Image$scharr_(
  dx,
  dy,
  ddepth = NULL,
  scale = 1,
  delta = 0,
  border_type = "reflect_101"
)

Arguments

dx

Integer. Order of x derivative: 0 or 1.

dy

Integer. Order of y derivative: 0 or 1. Exactly one of dx, dy must be 1.

ddepth

Character or NULL. Output depth: "CV_16S", "CV_32F", or "CV_64F". Default NULL (depth inferred from input; a message is emitted).

scale

Single positive numeric. Default 1.

delta

Single numeric. Default 0.

border_type

Character. Border handling mode. "wrap" is not supported. Default "reflect_101".

Returns

self invisibly.

Examples

\donttest{
img_path <- system.file("img", "brick_wall.jpg", package = "Retina")
img <- Image$new(img_path)
img$scharr_(1, 0)
img$plot()
}

---

Method filter2D()

Apply an arbitrary 2D convolution kernel. Returns a new Image.

Usage

Image$filter2D(
  kernel,
  ddepth = NULL,
  anchor = NULL,
  delta = 0,
  border_type = "reflect_101"
)

Arguments

kernel

Numeric matrix. The convolution kernel. Values are coerced to double.

ddepth

Character or NULL. Output depth. One of "CV_8U", "CV_16U", "CV_16S", "CV_32F", "CV_64F". When NULL (default), the output depth matches the input depth (OpenCV -1).

anchor

NULL (default, kernel centre) or a length-2 integer vector c(col, row) specifying the anchor pixel within the kernel (0-based).

delta

Single numeric. Constant added to every output pixel after convolution. Default 0.

border_type

Character. How to fill pixels outside the image boundary. "reflect_101" (default) mirrors the image excluding the edge pixel (e.g. dcb|abcde|dcb); "reflect" mirrors including the edge pixel (e.g. edcb|abcde|edcb); "replicate" repeats the nearest edge pixel; "constant" fills with a fixed value (0, i.e. black); "wrap" tiles the image at the boundary.

Returns

A new Image.

Examples

\donttest{
img_path <- system.file("img", "flower.jpg", package = "Retina")
img <- Image$new(img_path)
sharpen <- matrix(c(0,-1,0,-1,5,-1,0,-1,0), nrow = 3)
sharpened <- img$filter2D(sharpen)
sharpened$plot()
}

---

Method filter2D_()

Apply an arbitrary 2D convolution kernel in place.

Usage

Image$filter2D_(
  kernel,
  ddepth = NULL,
  anchor = NULL,
  delta = 0,
  border_type = "reflect_101"
)

Arguments

kernel

Numeric matrix. The convolution kernel.

ddepth

Character or NULL. Output depth. Default NULL (preserves input depth).

anchor

NULL (kernel centre) or c(col, row) (0-based).

delta

Single numeric. Additive offset. Default 0.

border_type

Character. Border handling mode. Default "reflect_101".

Returns

self invisibly.

Examples

\donttest{
img_path <- system.file("img", "flower.jpg", package = "Retina")
img <- Image$new(img_path)
sharpen <- matrix(c(0,-1,0,-1,5,-1,0,-1,0), nrow = 3)
img$filter2D_(sharpen)
img$plot()
}

---

Method sep_filter2D()

Apply a separable filter using two 1D kernels (one horizontal, one vertical). Returns a new Image. Equivalent to applying kernel_x along columns then kernel_y along rows, but computed more efficiently.

Usage

Image$sep_filter2D(
  kernel_x,
  kernel_y,
  ddepth = NULL,
  anchor = NULL,
  delta = 0,
  border_type = "reflect_101"
)

Arguments

kernel_x

Numeric vector. Horizontal (column-direction) 1D kernel.

kernel_y

Numeric vector. Vertical (row-direction) 1D kernel.

ddepth

Character or NULL. Output depth. One of "CV_8U", "CV_16U", "CV_16S", "CV_32F", "CV_64F". When NULL (default), the output depth matches the input depth.

anchor

NULL (default, kernel centres) or a length-2 integer vector c(pos_in_kernel_x, pos_in_kernel_y) (0-based).

delta

Single numeric. Constant added to every output pixel. Default 0.

border_type

Character. Border handling mode. Default "reflect_101".

Returns

A new Image.

Examples

\donttest{
img_path <- system.file("img", "flower.jpg", package = "Retina")
img <- Image$new(img_path)
blurred <- img$sep_filter2D(rep(1/3, 3), rep(1/3, 3))
blurred$plot()
}

---

Method sep_filter2D_()

Separable filter in place.

Usage

Image$sep_filter2D_(
  kernel_x,
  kernel_y,
  ddepth = NULL,
  anchor = NULL,
  delta = 0,
  border_type = "reflect_101"
)

Arguments

kernel_x

Numeric vector. Horizontal 1D kernel.

kernel_y

Numeric vector. Vertical 1D kernel.

ddepth

Character or NULL. Output depth. Default NULL.

anchor

NULL or c(pos_x, pos_y) (0-based). Default NULL (kernel centres).

delta

Single numeric. Default 0.

border_type

Character. Default "reflect_101".

Returns

self invisibly.

Examples

\donttest{
img_path <- system.file("img", "flower.jpg", package = "Retina")
img <- Image$new(img_path)
img$sep_filter2D_(rep(1/3, 3), rep(1/3, 3))
img$plot()
}

---

Method morph()

Apply a morphological operation. Returns a new Image.

Usage

Image$morph(
  operation,
  shape = "rect",
  size = 3L,
  kernel = NULL,
  iterations = 1L,
  border_type = "reflect_101"
)

Arguments

operation

Character. One of "erode" (shrinks bright regions), "dilate" (expands bright regions), "open" (erode then dilate — removes small bright spots), "close" (dilate then erode — fills small dark holes), "gradient" (dilate minus erode — highlights edges), "tophat" (image minus open — isolates bright features smaller than the kernel), "blackhat" (close minus image — isolates dark features smaller than the kernel).

shape

Character. Structuring element shape: "rect", "cross", or "ellipse". Ignored when kernel is supplied. Default "rect".

size

Positive odd integer. Side length of the structuring element. Ignored when kernel is supplied. Default 3L.

kernel

Optional numeric matrix used as the structuring element. Values are coerced to integers. Overrides shape and size when supplied.

iterations

Positive integer. For primitive operations ("erode", "dilate"), the number of times the operation is applied. For compound operations ("open", "close", "gradient", "tophat", "blackhat"), each internal erosion or dilation step is repeated iterations times independently (e.g., iterations = 2 with "open" erodes twice then dilates twice, not opens twice). Default 1L.

border_type

Character. How to fill pixels outside the image boundary. "reflect_101" (default) mirrors the image excluding the edge pixel (e.g. dcb|abcde|dcb); "reflect" mirrors including the edge pixel (e.g. edcb|abcde|edcb); "replicate" repeats the nearest edge pixel; "constant" fills with a fixed value (0, i.e. black). "wrap" is not supported by OpenCV for morphological operations.

Returns

A new Image.

Examples

\donttest{
img_path <- system.file("img", "flower.jpg", package = "Retina")
img <- Image$new(img_path)$convert_color("GRAY")
eroded <- img$morph("erode")
eroded$plot()
}

---

Method morph_()

Apply a morphological operation in place.

Usage

Image$morph_(
  operation,
  shape = "rect",
  size = 3L,
  kernel = NULL,
  iterations = 1L,
  border_type = "reflect_101"
)

Arguments

operation

Character. One of "erode" (shrinks bright regions), "dilate" (expands bright regions), "open" (erode then dilate — removes small bright spots), "close" (dilate then erode — fills small dark holes), "gradient" (dilate minus erode — highlights edges), "tophat" (image minus open — isolates bright features smaller than the kernel), "blackhat" (close minus image — isolates dark features smaller than the kernel).

shape

Character. Structuring element shape: "rect", "cross", or "ellipse". Ignored when kernel is supplied. Default "rect".

size

Positive odd integer. Side length of the structuring element. Ignored when kernel is supplied. Default 3L.

kernel

Optional numeric matrix used as the structuring element. Values are coerced to integers. Overrides shape and size when supplied.

iterations

Positive integer. For primitive operations ("erode", "dilate"), the number of times the operation is applied. For compound operations ("open", "close", "gradient", "tophat", "blackhat"), each internal erosion or dilation step is repeated iterations times independently (e.g., iterations = 2 with "open" erodes twice then dilates twice, not opens twice). Default 1L.

border_type

Character. How to fill pixels outside the image boundary. "reflect_101" (default) mirrors the image excluding the edge pixel (e.g. dcb|abcde|dcb); "reflect" mirrors including the edge pixel (e.g. edcb|abcde|edcb); "replicate" repeats the nearest edge pixel; "constant" fills with a fixed value (0, i.e. black). "wrap" is not supported by OpenCV for morphological operations.

Returns

self invisibly.

Examples

\donttest{
img_path <- system.file("img", "flower.jpg", package = "Retina")
img <- Image$new(img_path)$convert_color("GRAY")
img$morph_("erode")
img$plot()
}

---

Method resize()

Resize the image. Returns a new Image.

Usage

Image$resize(
  width = NULL,
  height = NULL,
  fx = NULL,
  fy = NULL,
  interpolation = "linear"
)

Arguments

width

Positive integer. Output width in pixels. Supply with height; mutually exclusive with fx/fy.

height

Positive integer. Output height in pixels.

fx

Positive numeric. Horizontal scale factor. Supply with fy; mutually exclusive with width/height.

fy

Positive numeric. Vertical scale factor.

interpolation

Character. One of "nearest", "linear", "cubic", "area", "lanczos4". Default "linear".

Returns

A new Image.

Examples

\donttest{
img_path <- system.file("img", "flower.jpg", package = "Retina")
img <- Image$new(img_path)
img$resize(width = 320L, height = 240L)$plot()
img$resize(fx = 0.5, fy = 0.5)$plot()
}

---

Method resize_()

Resize the image in place.

Usage

Image$resize_(
  width = NULL,
  height = NULL,
  fx = NULL,
  fy = NULL,
  interpolation = "linear"
)

Arguments

width

Positive integer. Output width in pixels.

height

Positive integer. Output height in pixels.

fx

Positive numeric. Horizontal scale factor.

fy

Positive numeric. Vertical scale factor.

interpolation

Character. One of "nearest", "linear", "cubic", "area", "lanczos4". Default "linear".

Returns

self invisibly.

Examples

\donttest{
img_path <- system.file("img", "flower.jpg", package = "Retina")
img <- Image$new(img_path)
img$resize_(fx = 0.5, fy = 0.5)
img$plot()
}

---

Method rotate()

Rotate the image. Returns a new Image. Output retains original dimensions; content outside the canvas is clipped.

Usage

Image$rotate(
  angle,
  cx = NULL,
  cy = NULL,
  scale = 1,
  interpolation = "linear",
  border_type = "reflect_101"
)

Arguments

angle

Single numeric. Rotation angle in degrees, counter-clockwise.

cx

Single positive numeric. X coordinate of the rotation centre (1-based). Defaults to image centre.

cy

Single positive numeric. Y coordinate of the rotation centre (1-based). Defaults to image centre.

scale

Single positive numeric. Isotropic scale factor applied during rotation. Default 1.

interpolation

Character. One of "nearest", "linear", "cubic", "area", "lanczos4". Default "linear".

border_type

Character. Pixel extrapolation method. One of "reflect_101", "reflect", "replicate", "constant", "wrap". Default "reflect_101".

Returns

A new Image.

Examples

\donttest{
img_path <- system.file("img", "flower.jpg", package = "Retina")
img <- Image$new(img_path)
img$rotate(45)$plot()
}

---

Method rotate_()

Rotate the image in place.

Usage

Image$rotate_(
  angle,
  cx = NULL,
  cy = NULL,
  scale = 1,
  interpolation = "linear",
  border_type = "reflect_101"
)

Arguments

angle

Single numeric. Rotation angle in degrees, counter-clockwise.

cx

Single positive numeric. X coordinate of the rotation centre (1-based). Defaults to image centre.

cy

Single positive numeric. Y coordinate of the rotation centre (1-based). Defaults to image centre.

scale

Single positive numeric. Isotropic scale factor. Default 1.

interpolation

Character. One of "nearest", "linear", "cubic", "area", "lanczos4". Default "linear".

border_type

Character. Pixel extrapolation method. One of "reflect_101", "reflect", "replicate", "constant", "wrap". Default "reflect_101".

Returns

self invisibly.

Examples

\donttest{
img_path <- system.file("img", "flower.jpg", package = "Retina")
img <- Image$new(img_path)
img$rotate_(45)
img$plot()
}

---

Method flip()

Flip the image horizontally, vertically, or both. Returns a new Image.

Usage

Image$flip(flip_h = FALSE, flip_v = FALSE)

Arguments

flip_h

Logical scalar. If TRUE, flip left-right. Default FALSE.

flip_v

Logical scalar. If TRUE, flip top-bottom. Default FALSE.

Returns

A new Image.

Examples

\donttest{
img_path <- system.file("img", "flower.jpg", package = "Retina")
img <- Image$new(img_path)
img$flip(flip_h = TRUE)$plot()
}

---

Method flip_()

Flip the image in place.

Usage

Image$flip_(flip_h = FALSE, flip_v = FALSE)

Arguments

flip_h

Logical scalar. If TRUE, flip left-right. Default FALSE.

flip_v

Logical scalar. If TRUE, flip top-bottom. Default FALSE.

Returns

self invisibly.

Examples

\donttest{
img_path <- system.file("img", "flower.jpg", package = "Retina")
img <- Image$new(img_path)
img$flip_(flip_v = TRUE)
img$plot()
}

---

Method crop()

Crop the image to a rectangular region. Returns a new Image. Coordinates are 1-based.

Usage

Image$crop(x1, y1, x2, y2)

Arguments

x1

Single positive integer. Left column (inclusive, 1-based).

y1

Single positive integer. Top row (inclusive, 1-based).

x2

Single positive integer. Right column (inclusive, 1-based). Must be greater than x1 and <= ncol.

y2

Single positive integer. Bottom row (inclusive, 1-based). Must be greater than y1 and <= nrow.

Returns

A new Image.

Examples

\donttest{
img_path <- system.file("img", "flower.jpg", package = "Retina")
img <- Image$new(img_path)
img$crop(1L, 1L, 100L, 100L)$plot()
}

---

Method crop_()

Crop the image in place.

Usage

Image$crop_(x1, y1, x2, y2)

Arguments

x1

Single positive integer. Left column (inclusive, 1-based).

y1

Single positive integer. Top row (inclusive, 1-based).

x2

Single positive integer. Right column (inclusive, 1-based).

y2

Single positive integer. Bottom row (inclusive, 1-based).

Returns

self invisibly.

Examples

\donttest{
img_path <- system.file("img", "flower.jpg", package = "Retina")
img <- Image$new(img_path)
img$crop_(1L, 1L, 100L, 100L)
img$plot()
}

---

Method warp_affine()

Apply an affine transformation to the image. Returns a new Image. Output defaults to the same dimensions as the input; content outside the canvas is clipped.

Usage

Image$warp_affine(
  m,
  width = NULL,
  height = NULL,
  interpolation = "linear",
  border_type = "reflect_101"
)

Arguments

m

A 2x3 numeric matrix representing the affine transformation. Build one with affine_translate, affine_scale, affine_shear, affine_rotate, or affine_from_points. Compose multiple transforms by embedding into 3x3 with rbind(m, c(0, 0, 1)) then multiplying with %*%.

width

Positive integer. Output width in pixels. Default: self$ncol.

height

Positive integer. Output height in pixels. Default: self$nrow.

interpolation

Character. One of "nearest", "linear", "cubic", "area", "lanczos4". Default "linear".

border_type

Character. How to fill pixels outside the image boundary. "reflect_101" (default) mirrors the image excluding the edge pixel (e.g. dcb|abcde|dcb); "reflect" mirrors including the edge pixel (e.g. edcb|abcde|edcb); "replicate" repeats the nearest edge pixel; "wrap" tiles the image; "constant" fills with a fixed value (0, i.e. black).

Returns

A new Image.

Examples

\donttest{
img_path <- system.file("img", "flower.jpg", package = "Retina")
img <- Image$new(img_path)
m <- affine_translate(50, 30)
img$warp_affine(m)$plot()
}

---

Method warp_affine_()

Apply an affine transformation to the image in place.

Usage

Image$warp_affine_(
  m,
  width = NULL,
  height = NULL,
  interpolation = "linear",
  border_type = "reflect_101"
)

Arguments

m

A 2x3 numeric matrix representing the affine transformation. Build one with affine_translate, affine_scale, affine_shear, affine_rotate, or affine_from_points. Compose multiple transforms by embedding into 3x3 with rbind(m, c(0, 0, 1)) then multiplying with %*%.

width

Positive integer. Output width in pixels. Default: self$ncol.

height

Positive integer. Output height in pixels. Default: self$nrow.

interpolation

Character. One of "nearest", "linear", "cubic", "area", "lanczos4". Default "linear".

border_type

Character. How to fill pixels outside the image boundary. "reflect_101" (default) mirrors the image excluding the edge pixel (e.g. dcb|abcde|dcb); "reflect" mirrors including the edge pixel (e.g. edcb|abcde|edcb); "replicate" repeats the nearest edge pixel; "wrap" tiles the image; "constant" fills with a fixed value (0, i.e. black).

Returns

self invisibly.

Examples

\donttest{
img_path <- system.file("img", "flower.jpg", package = "Retina")
img <- Image$new(img_path)
img$warp_affine_(affine_translate(50, 30))
img$plot()
}

---

Method warp_perspective()

Apply a perspective transformation to the image. Returns a new Image. Output defaults to the same dimensions as the input; content outside the canvas is clipped.

Usage

Image$warp_perspective(
  m,
  width = NULL,
  height = NULL,
  interpolation = "linear",
  border_type = "reflect_101"
)

Arguments

m

A 3x3 numeric matrix representing the perspective transformation. Build one with perspective_from_points.

width

Positive integer. Output width in pixels. Default: self$ncol.

height

Positive integer. Output height in pixels. Default: self$nrow.

interpolation

Character. One of "nearest", "linear", "cubic", "area", "lanczos4". Default "linear".

border_type

Character. How to fill pixels outside the image boundary. "reflect_101" (default) mirrors the image excluding the edge pixel (e.g. dcb|abcde|dcb); "reflect" mirrors including the edge pixel (e.g. edcb|abcde|edcb); "replicate" repeats the nearest edge pixel; "wrap" tiles the image; "constant" fills with a fixed value (0, i.e. black).

Returns

A new Image.

Examples

\donttest{
img_path <- system.file("img", "flower.jpg", package = "Retina")
img <- Image$new(img_path)
w <- img$ncol; h <- img$nrow
src <- matrix(c(1, 1,  w, 1,  w, h,  1, h), nrow = 4, byrow = TRUE)
dst <- matrix(c(round(w*0.1), 1,  w, 1,  w, h,  1, h), nrow = 4, byrow = TRUE)
m <- perspective_from_points(src, dst)
img$warp_perspective(m)$plot()
}

---

Method warp_perspective_()

Apply a perspective transformation to the image in place.

Usage

Image$warp_perspective_(
  m,
  width = NULL,
  height = NULL,
  interpolation = "linear",
  border_type = "reflect_101"
)

Arguments

m

A 3x3 numeric matrix representing the perspective transformation. Build one with perspective_from_points.

width

Positive integer. Output width in pixels. Default: self$ncol.

height

Positive integer. Output height in pixels. Default: self$nrow.

interpolation

Character. One of "nearest", "linear", "cubic", "area", "lanczos4". Default "linear".

border_type

Character. How to fill pixels outside the image boundary. "reflect_101" (default) mirrors the image excluding the edge pixel (e.g. dcb|abcde|dcb); "reflect" mirrors including the edge pixel (e.g. edcb|abcde|edcb); "replicate" repeats the nearest edge pixel; "wrap" tiles the image; "constant" fills with a fixed value (0, i.e. black).

Returns

self invisibly.

Examples

\donttest{
img_path <- system.file("img", "flower.jpg", package = "Retina")
img <- Image$new(img_path)
w <- img$ncol; h <- img$nrow
src <- matrix(c(1, 1,  w, 1,  w, h,  1, h), nrow = 4, byrow = TRUE)
dst <- matrix(c(round(w*0.1), 1,  w, 1,  w, h,  1, h), nrow = 4, byrow = TRUE)
img$warp_perspective_(perspective_from_points(src, dst))
img$plot()
}

---

Method border()

Add a border around the image.

The argument order `(top, left, bottom, right)` is deliberately different from the CSS shorthand (`top, right, bottom, left`) and from OpenCV's `copyMakeBorder` (`top, bottom, left, right`). With this order, the two-argument form `$border(v, h)` adds `v` pixels vertically (top and bottom) and `h` pixels horizontally (left and right) — the most natural two-argument case for symmetric borders.

Usage

Image$border(
  top,
  left = top,
  bottom = top,
  right = left,
  type = "constant",
  value = 0
)

Arguments

top

Integer. Border width in pixels on the top edge.

left

Integer. Border width on the left edge. Defaults to `top`.

bottom

Integer. Border width on the bottom edge. Defaults to `top`.

right

Integer. Border width on the right edge. Defaults to `left`.

type

Character. Border fill mode. `"constant"` (default) fills with a fixed colour (see `value`); `"reflect"` mirrors the image including the edge pixel; `"reflect_101"` mirrors excluding the edge pixel; `"replicate"` repeats the nearest edge pixel; `"wrap"` tiles the image.

value

Numeric vector of length 1 or `nchan`. Fill colour used when `type = "constant"`. Recycled to `nchan` values. Default 0 (black).

Returns

A new `Image`.

---

Method border_()

Add a border around the image, in place.

See `$border()` for the rationale behind the argument order `(top, left, bottom, right)`.

Usage

Image$border_(
  top,
  left = top,
  bottom = top,
  right = left,
  type = "constant",
  value = 0
)

Arguments

top

Integer. Border width on the top edge.

left

Integer. Defaults to `top`.

bottom

Integer. Defaults to `top`.

right

Integer. Defaults to `left`.

type

Character. Border fill mode. `"constant"` (default) fills with a fixed colour (see `value`); `"reflect"` mirrors the image including the edge pixel; `"reflect_101"` mirrors excluding the edge pixel; `"replicate"` repeats the nearest edge pixel; `"wrap"` tiles the image.

value

Numeric vector of length 1 or `nchan`. Fill colour used when `type = "constant"`. Recycled to `nchan` values. Default 0 (black).

Returns

`self` invisibly.

---

Method tile()

Tile (repeat) the image in a grid.

Usage

Image$tile(nrow, ncol = nrow)

Arguments

nrow

Integer. Number of vertical repetitions.

ncol

Integer. Number of horizontal repetitions. Defaults to `nrow`.

Returns

A new `Image` with dimensions `nrow * self$nrow` x `ncol * self$ncol`.

---

Method tile_()

Tile (repeat) the image in a grid, in place.

Usage

Image$tile_(nrow, ncol = nrow)

Arguments

nrow

Integer. Number of vertical repetitions.

ncol

Integer. Number of horizontal repetitions. Defaults to `nrow`.

Returns

`self` invisibly.

---

Method set_to()

Set all pixels — or only masked pixels — to a constant value.

Usage

Image$set_to(value, mask = NULL)

Arguments

value

Numeric scalar or vector of length nchan. Recycled to nchan channels. No NAs.

mask

NULL (apply to all pixels) or a single-channel CV_8U Image with the same nrow and ncol. Non-zero pixels mark where value is written.

Returns

A new Image.

---

Method set_to_()

Set all pixels — or only masked pixels — to a constant value, in place.

Usage

Image$set_to_(value, mask = NULL)

Arguments

value

Numeric scalar or vector of length nchan. Recycled to nchan channels. No NAs.

mask

NULL or a single-channel CV_8U Image same size as self.

Returns

self invisibly.

---

Method threshold()

Apply a threshold to the image.

Usage

Image$threshold(thresh, maxval = 255, type = "binary", bins = 256L)

Arguments

thresh

Single finite numeric or one of 17 lowercase auto-threshold method strings. When numeric, passed directly to OpenCV. When a string, the threshold is auto-computed from the image histogram.

maxval

Single finite numeric. Value assigned to above-threshold pixels in `"binary"` and `"binary_inv"` modes. Default `255`.

type

Character. How pixel values are mapped relative to the threshold `T`. `"binary"` (default): above `T` → `maxval`, at or below → 0. `"binary_inv"`: above `T` → 0, at or below → `maxval`. `"trunc"`: above `T` → `T`, at or below → unchanged (acts as a ceiling). `"tozero"`: at or below `T` → 0, above → unchanged. `"tozero_inv"`: above `T` → 0, at or below → unchanged. `maxval` is only used by `"binary"` and `"binary_inv"`.

bins

Single integer >= 2. Histogram bins for auto-threshold on non-`CV_8U` images. Ignored when `thresh` is numeric or for `CV_8U`. Default `256`.

Returns

A new `Image`.

---

Method threshold_()

Apply a threshold to the image, in place.

Usage

Image$threshold_(thresh, maxval = 255, type = "binary", bins = 256L)

Arguments

thresh

See `$threshold()`.

maxval

See `$threshold()`.

type

See `$threshold()` for a description of all five modes.

bins

See `$threshold()`.

Returns

`self` invisibly.

---

Method adaptive_threshold()

Apply an adaptive threshold to the image.

Usage

Image$adaptive_threshold(
  maxval = 255,
  method = "mean",
  type = "binary",
  block_size = 11L,
  offset = 2
)

Arguments

maxval

Single finite numeric. Value for above-threshold pixels. Default `255`.

method

`"mean"` (local neighbourhood mean) or `"gaussian"` (Gaussian-weighted neighbourhood). Default `"mean"`.

type

`"binary"` (default): pixels above the local threshold → `maxval`, others → 0. `"binary_inv"`: inverted — pixels above → 0, others → `maxval`.

block_size

Single odd integer >= 3. Neighbourhood size. Default `11`.

offset

Single finite numeric. Constant subtracted from the local mean (OpenCV's `C` parameter). May be negative. Default `2`.

Returns

A new single-channel `CV_8U` `Image` with colorspace `"GRAY"`.

---

Method adaptive_threshold_()

Apply an adaptive threshold to the image, in place.

Usage

Image$adaptive_threshold_(
  maxval = 255,
  method = "mean",
  type = "binary",
  block_size = 11L,
  offset = 2
)

Arguments

maxval

See `$adaptive_threshold()`.

method

See `$adaptive_threshold()`.

type

See `$adaptive_threshold()` for a description of both modes.

block_size

See `$adaptive_threshold()`.

offset

See `$adaptive_threshold()`.

Returns

`self` invisibly.

---

Method in_range()

Create a binary mask where each pixel is 255 if all channels fall within `[lower[k], upper[k]]`, and 0 otherwise.

Usage

Image$in_range(lower, upper)

Arguments

lower

Numeric vector of length 1 or `nchan`. Lower bound per channel. Recycled to `nchan`. No NAs; all finite.

upper

Numeric vector of length 1 or `nchan`. Upper bound per channel. Recycled to `nchan`. No NAs; all finite.

Returns

A new single-channel `CV_8U` `Image` with colorspace `"GRAY"`.

---

Method in_range_()

Create a binary mask in place. See `$in_range()`.

Usage

Image$in_range_(lower, upper)

Arguments

lower

See `$in_range()`.

upper

See `$in_range()`.

Returns

`self` invisibly.

---

Method draw_line()

Draw a line segment on the image. Returns a new Image.

Usage

Image$draw_line(x1, y1, x2, y2, color, thickness = 1L, line_type = "line_8")

Arguments

x1

Positive integer. X (column) coordinate of the start point.

y1

Positive integer. Y (row) coordinate of the start point.

x2

Positive integer. X (column) coordinate of the end point.

y2

Positive integer. Y (row) coordinate of the end point.

color

An R color name, hex string, or numeric BGR(A) vector.

thickness

Positive integer. Line width in pixels. Default 1L.

line_type

Character. One of "line_4" (4-connected), "line_8" (8-connected, default), "aa" (anti-aliased; 8-bit images only).

Returns

A new Image.

Examples

\donttest{
img_path <- system.file("img", "flower.jpg", package = "Retina")
img <- Image$new(img_path)
img$draw_line(1, 1, 100, 100, color = "red")$plot()
}

---

Method draw_line_()

Draw a line segment on the image in place.

Usage

Image$draw_line_(x1, y1, x2, y2, color, thickness = 1L, line_type = "line_8")

Arguments

x1

Positive integer. X (column) coordinate of the start point.

y1

Positive integer. Y (row) coordinate of the start point.

x2

Positive integer. X (column) coordinate of the end point.

y2

Positive integer. Y (row) coordinate of the end point.

color

An R color name, hex string, or numeric BGR(A) vector.

thickness

Positive integer. Line width in pixels. Default 1L.

line_type

Character. One of "line_4", "line_8" (default), "aa".

Returns

self invisibly.

---

Method draw_arrow()

Draw an arrowed line on the image. Returns a new Image.

Usage

Image$draw_arrow(
  x1,
  y1,
  x2,
  y2,
  color,
  thickness = 1L,
  line_type = "line_8",
  tip_length = 0.1
)

Arguments

x1

Positive integer. X coordinate of the arrow tail.

y1

Positive integer. Y coordinate of the arrow tail.

x2

Positive integer. X coordinate of the arrowhead tip.

y2

Positive integer. Y coordinate of the arrowhead tip.

color

An R color name, hex string, or numeric BGR(A) vector.

thickness

Positive integer. Line width in pixels. Default 1L.

line_type

Character. One of "line_4", "line_8" (default), "aa".

tip_length

Numeric. Arrowhead length as a proportion of total arrow length. Negative values produce a reversed arrowhead. Default 0.1.

Returns

A new Image.

Examples

\donttest{
img_path <- system.file("img", "flower.jpg", package = "Retina")
img <- Image$new(img_path)
img$draw_arrow(10, 10, 100, 100, color = "blue")$plot()
}

---

Method draw_arrow_()

Draw an arrowed line on the image in place.

Usage

Image$draw_arrow_(
  x1,
  y1,
  x2,
  y2,
  color,
  thickness = 1L,
  line_type = "line_8",
  tip_length = 0.1
)

Arguments

x1

Positive integer. X coordinate of the arrow tail.

y1

Positive integer. Y coordinate of the arrow tail.

x2

Positive integer. X coordinate of the arrowhead tip.

y2

Positive integer. Y coordinate of the arrowhead tip.

color

An R color name, hex string, or numeric BGR(A) vector.

thickness

Positive integer. Line width in pixels. Default 1L.

line_type

Character. One of "line_4", "line_8" (default), "aa".

tip_length

Numeric. Arrowhead length as a proportion of total arrow length. Default 0.1.

Returns

self invisibly.

---

Method draw_rectangle()

Draw a rectangle outline (or filled rectangle) on the image. Returns a new Image.

Usage

Image$draw_rectangle(
  x1,
  y1,
  x2,
  y2,
  color,
  thickness = 1L,
  line_type = "line_8",
  filled = FALSE
)

Arguments

x1

Integer. X coordinate of one corner.

y1

Integer. Y coordinate of one corner.

x2

Integer. X coordinate of the opposite corner.

y2

Integer. Y coordinate of the opposite corner.

color

An R color name, hex string, or numeric BGR(A) vector.

thickness

Positive integer. Outline width in pixels. Ignored when filled = TRUE. Default 1L.

line_type

Character. One of "line_4", "line_8" (default), "aa".

filled

Logical. If TRUE, draw a filled rectangle. Default FALSE.

Returns

A new Image.

Examples

\donttest{
img_path <- system.file("img", "flower.jpg", package = "Retina")
img <- Image$new(img_path)
img$draw_rectangle(10, 10, 100, 100, color = "blue", filled = TRUE)$plot()
}

---

Method draw_rectangle_()

Draw a rectangle on the image in place.

Usage

Image$draw_rectangle_(
  x1,
  y1,
  x2,
  y2,
  color,
  thickness = 1L,
  line_type = "line_8",
  filled = FALSE
)

Arguments

x1

Integer. X coordinate of one corner.

y1

Integer. Y coordinate of one corner.

x2

Integer. X coordinate of the opposite corner.

y2

Integer. Y coordinate of the opposite corner.

color

An R color name, hex string, or numeric BGR(A) vector.

thickness

Positive integer. Outline width. Ignored when filled = TRUE. Default 1L.

line_type

Character. One of "line_4", "line_8" (default), "aa".

filled

Logical. If TRUE, fill the rectangle. Default FALSE.

Returns

self invisibly.

---

Method draw_circle()

Draw a circle outline (or filled circle) on the image. Returns a new Image.

Usage

Image$draw_circle(
  x,
  y,
  radius,
  color,
  thickness = 1L,
  line_type = "line_8",
  filled = FALSE
)

Arguments

x

Integer. X coordinate of the center.

y

Integer. Y coordinate of the center.

radius

Non-negative integer. Circle radius in pixels.

color

An R color name, hex string, or numeric BGR(A) vector.

thickness

Positive integer. Outline width. Ignored when filled = TRUE. Default 1L.

line_type

Character. One of "line_4", "line_8" (default), "aa".

filled

Logical. If TRUE, draw a filled circle. Default FALSE.

Returns

A new Image.

Examples

\donttest{
img_path <- system.file("img", "flower.jpg", package = "Retina")
img <- Image$new(img_path)
img$draw_circle(100, 100, 50, color = "green", filled = TRUE)$plot()
}

---

Method draw_circle_()

Draw a circle on the image in place.

Usage

Image$draw_circle_(
  x,
  y,
  radius,
  color,
  thickness = 1L,
  line_type = "line_8",
  filled = FALSE
)

Arguments

x

Integer. X coordinate of the center.

y

Integer. Y coordinate of the center.

radius

Non-negative integer. Circle radius in pixels.

color

An R color name, hex string, or numeric BGR(A) vector.

thickness

Positive integer. Outline width. Ignored when filled = TRUE. Default 1L.

line_type

Character. One of "line_4", "line_8" (default), "aa".

filled

Logical. If TRUE, fill the circle. Default FALSE.

Returns

self invisibly.

---

Method draw_ellipse()

Draw an ellipse outline (or filled ellipse) on the image. Returns a new Image.

Usage

Image$draw_ellipse(
  x,
  y,
  rx,
  ry,
  angle = 0,
  color,
  thickness = 1L,
  line_type = "line_8",
  filled = FALSE
)

Arguments

x

Integer. X coordinate of the ellipse center.

y

Integer. Y coordinate of the ellipse center.

rx

Positive integer. Horizontal semi-axis length in pixels (before rotation).

ry

Positive integer. Vertical semi-axis length in pixels (before rotation).

angle

Numeric. Rotation of the ellipse in degrees (clockwise). Default 0.

color

An R color name, hex string, or numeric BGR(A) vector.

thickness

Positive integer. Outline width. Ignored when filled = TRUE. Default 1L.

line_type

Character. One of "line_4", "line_8" (default), "aa".

filled

Logical. If TRUE, draw a filled ellipse. Default FALSE.

Returns

A new Image.

Examples

\donttest{
img_path <- system.file("img", "flower.jpg", package = "Retina")
img <- Image$new(img_path)
img$draw_ellipse(100, 100, 80L, 40L, angle = 30, color = "red")$plot()
}

---

Method draw_ellipse_()

Draw an ellipse on the image in place.

Usage

Image$draw_ellipse_(
  x,
  y,
  rx,
  ry,
  angle = 0,
  color,
  thickness = 1L,
  line_type = "line_8",
  filled = FALSE
)

Arguments

x

Integer. X coordinate of the ellipse center.

y

Integer. Y coordinate of the ellipse center.

rx

Positive integer. Horizontal semi-axis length in pixels.

ry

Positive integer. Vertical semi-axis length in pixels.

angle

Numeric. Rotation in degrees. Default 0.

color

An R color name, hex string, or numeric BGR(A) vector.

thickness

Positive integer. Outline width. Ignored when filled = TRUE. Default 1L.

line_type

Character. One of "line_4", "line_8" (default), "aa".

filled

Logical. If TRUE, fill the ellipse. Default FALSE.

Returns

self invisibly.

---

Method draw_arc()

Draw a partial ellipse arc on the image. Returns a new Image.

Usage

Image$draw_arc(
  x,
  y,
  rx,
  ry,
  angle = 0,
  start_angle,
  end_angle,
  color,
  thickness = 1L,
  line_type = "line_8"
)

Arguments

x

Integer. X coordinate of the ellipse center.

y

Integer. Y coordinate of the ellipse center.

rx

Positive integer. Horizontal semi-axis length in pixels.

ry

Positive integer. Vertical semi-axis length in pixels.

angle

Numeric. Rotation of the ellipse in degrees. Default 0.

start_angle

Numeric. Start angle of the arc in degrees.

end_angle

Numeric. End angle of the arc in degrees. If start_angle > end_angle, OpenCV swaps them automatically.

color

An R color name, hex string, or numeric BGR(A) vector.

thickness

Positive integer. Line width in pixels. Default 1L.

line_type

Character. One of "line_4", "line_8" (default), "aa".

Returns

A new Image.

Examples

\donttest{
img_path <- system.file("img", "flower.jpg", package = "Retina")
img <- Image$new(img_path)
img$draw_arc(100, 100, 80L, 40L, start_angle = 0, end_angle = 180,
             color = "red")$plot()
}

---

Method draw_arc_()

Draw a partial ellipse arc on the image in place.

Usage

Image$draw_arc_(
  x,
  y,
  rx,
  ry,
  angle = 0,
  start_angle,
  end_angle,
  color,
  thickness = 1L,
  line_type = "line_8"
)

Arguments

x

Integer. X coordinate of the ellipse center.

y

Integer. Y coordinate of the ellipse center.

rx

Positive integer. Horizontal semi-axis length in pixels.

ry

Positive integer. Vertical semi-axis length in pixels.

angle

Numeric. Rotation in degrees. Default 0.

start_angle

Numeric. Start angle of the arc in degrees.

end_angle

Numeric. End angle of the arc in degrees.

color

An R color name, hex string, or numeric BGR(A) vector.

thickness

Positive integer. Line width. Default 1L.

line_type

Character. One of "line_4", "line_8" (default), "aa".

Returns

self invisibly.

---

Method draw_polyline()

Draw a polyline (open or closed polygon outline) on the image. Returns a new Image.

Usage

Image$draw_polyline(
  pts,
  closed = FALSE,
  color,
  thickness = 1L,
  line_type = "line_8"
)

Arguments

pts

A numeric matrix with exactly 2 columns (x, y) and at least 2 rows. Each row is a vertex.

closed

Logical. If TRUE, connect the last vertex back to the first. Default FALSE.

color

An R color name, hex string, or numeric BGR(A) vector.

thickness

Positive integer. Line width in pixels. Default 1L.

line_type

Character. One of "line_4", "line_8" (default), "aa".

Returns

A new Image.

Examples

\donttest{
img_path <- system.file("img", "flower.jpg", package = "Retina")
img <- Image$new(img_path)
pts <- matrix(c(10, 10, 100, 10, 55, 90), nrow = 3, ncol = 2, byrow = TRUE)
img$draw_polyline(pts, closed = TRUE, color = "yellow")$plot()
}

---

Method draw_polyline_()

Draw a polyline on the image in place.

Usage

Image$draw_polyline_(
  pts,
  closed = FALSE,
  color,
  thickness = 1L,
  line_type = "line_8"
)

Arguments

pts

A numeric matrix with exactly 2 columns and at least 2 rows.

closed

Logical. If TRUE, close the polygon. Default FALSE.

color

An R color name, hex string, or numeric BGR(A) vector.

thickness

Positive integer. Line width. Default 1L.

line_type

Character. One of "line_4", "line_8" (default), "aa".

Returns

self invisibly.

---

Method fill_poly()

Draw a filled polygon on the image. Returns a new Image.

Usage

Image$fill_poly(pts, color, line_type = "line_8")

Arguments

pts

A numeric matrix with exactly 2 columns (x, y) and at least 3 rows. Each row is a vertex.

color

An R color name, hex string, or numeric BGR(A) vector.

line_type

Character. One of "line_4", "line_8" (default), "aa".

Returns

A new Image.

Examples

\donttest{
img_path <- system.file("img", "flower.jpg", package = "Retina")
img <- Image$new(img_path)
pts <- matrix(c(10, 10, 100, 10, 55, 90), nrow = 3, ncol = 2, byrow = TRUE)
img$fill_poly(pts, color = "cyan")$plot()
}

---

Method fill_poly_()

Draw a filled polygon on the image in place.

Usage

Image$fill_poly_(pts, color, line_type = "line_8")

Arguments

pts

A numeric matrix with exactly 2 columns and at least 3 rows.

color

An R color name, hex string, or numeric BGR(A) vector.

line_type

Character. One of "line_4", "line_8" (default), "aa".

Returns

self invisibly.

---

Method draw_text()

Draw text on the image. Returns a new Image.

Usage

Image$draw_text(
  text,
  x,
  y,
  font = "simplex",
  font_size = 1,
  italic = FALSE,
  color,
  thickness = 1L,
  line_type = "line_8"
)

Arguments

text

Character. The string to draw.

x

Integer. X coordinate of the bottom-left corner of the text bounding box.

y

Integer. Y coordinate of the bottom-left corner of the text bounding box.

font

Character. One of "simplex" (default), "plain", "duplex", "complex", "triplex", "complex_small", "script_simplex", "script_complex".

font_size

Numeric. Scale factor applied to the base font size. Negative values mirror/reverse the text. Default 1.

italic

Logical. If TRUE, use the italic variant of the font. Default FALSE.

color

An R color name, hex string, or numeric BGR(A) vector.

thickness

Positive integer. Character stroke width. Default 1L.

line_type

Character. One of "line_4", "line_8" (default), "aa".

Returns

A new Image.

Examples

\donttest{
img_path <- system.file("img", "flower.jpg", package = "Retina")
img <- Image$new(img_path)
img$draw_text("Hello", 10, 50, font = "duplex", font_size = 1.5,
              color = "white")$plot()
}

---

Method draw_text_()

Draw text on the image in place.

Usage

Image$draw_text_(
  text,
  x,
  y,
  font = "simplex",
  font_size = 1,
  italic = FALSE,
  color,
  thickness = 1L,
  line_type = "line_8"
)

Arguments

text

Character. The string to draw.

x

Integer. X coordinate of the bottom-left corner of the text.

y

Integer. Y coordinate of the bottom-left corner of the text.

font

Character. Font face name. Default "simplex".

font_size

Numeric. Scale factor. Negative mirrors the text. Default 1.

italic

Logical. Italic variant. Default FALSE.

color

An R color name, hex string, or numeric BGR(A) vector.

thickness

Positive integer. Stroke width. Default 1L.

line_type

Character. One of "line_4", "line_8" (default), "aa".

Returns

self invisibly.

---

Method hist()

Compute a per-channel histogram of pixel values.

Usage

Image$hist(bins = 256L, range = NULL, freq = TRUE)

Arguments

bins

Single positive integer. Number of histogram bins. Default 256.

range

Length-2 numeric vector c(lo, hi) giving the pixel-value range to histogram. NULL (default) applies a depth-appropriate default and emits a message.

freq

Logical. TRUE (default): count column contains raw pixel counts (consistent with base R hist(freq = TRUE)). FALSE: count column contains probability densities (counts / (total_pixels * bin_width)).

Returns

A tidy data frame with columns bin_center (double), channel (character), and count (double). One row per bin per channel, ordered by channel then ascending bin_center.

Examples

\donttest{
img_path <- system.file("img", "flower.jpg", package = "Retina")
img <- Image$new(img_path)$to_gray()
h <- img$hist(bins = 256L, range = c(0, 256))
# plot with ggplot2:
# ggplot2::ggplot(h, ggplot2::aes(x = bin_center, y = count)) +
#   ggplot2::geom_col()
}

---

Method hist_eq()

Apply global histogram equalization. Returns a new Image. Requires a single-channel CV_8U image. For multi-channel images, use split_channels() then apply per channel.

Usage

Image$hist_eq()

Returns

A new CV_8U single-channel Image.

Examples

\donttest{
img_path <- system.file("img", "brick_wall.jpg", package = "Retina")
img <- Image$new(img_path)$to_gray()
eq  <- img$hist_eq()
eq$plot()
}

---

Method hist_eq_()

Apply global histogram equalization in place. Requires a single-channel CV_8U image.

Usage

Image$hist_eq_()

Returns

self invisibly.

Examples

\donttest{
img_path <- system.file("img", "brick_wall.jpg", package = "Retina")
img <- Image$new(img_path)$to_gray()
img$hist_eq_()
img$plot()
}

---

Method hist_match()

Match the histogram of this image to a reference histogram. Returns a new Image. Requires a single-channel CV_8U image.

Usage

Image$hist_match(ref)

Arguments

ref

A data frame as produced by $hist(bins = 256L) with columns bin_center, channel, and count. Must have exactly 256 rows (one per 8-bit value).

Returns

A new CV_8U single-channel Image.

Examples

\donttest{
img_path <- system.file("img", "brick_wall.jpg", package = "Retina")
ref_path <- system.file("img", "flower.jpg",     package = "Retina")
src <- Image$new(img_path)$to_gray()
ref <- Image$new(ref_path)$to_gray()
ref_hist <- ref$hist(bins = 256L, range = c(0, 255))
out <- src$hist_match(ref_hist)
out$plot()
}

---

Method hist_match_()

Match the histogram of this image to a reference, in place.

Usage

Image$hist_match_(ref)

Arguments

ref

See $hist_match().

Returns

self invisibly.

Examples

\donttest{
img_path <- system.file("img", "brick_wall.jpg", package = "Retina")
ref_path <- system.file("img", "flower.jpg",     package = "Retina")
src <- Image$new(img_path)$to_gray()
ref <- Image$new(ref_path)$to_gray()
ref_hist <- ref$hist(bins = 256L, range = c(0, 256))
src$hist_match_(ref_hist)
src$plot()
}

---

Method CLAHE()

Apply Contrast Limited Adaptive Histogram Equalization (CLAHE). Returns a new Image. Requires a single-channel CV_8U or CV_16U image.

Usage

Image$CLAHE(clip_limit = 40, tile_grid_size = c(8L, 8L))

Arguments

clip_limit

Single positive numeric. Threshold for contrast limiting — higher values allow more contrast enhancement, lower values reduce noise amplification. Default 40.0.

tile_grid_size

Length-1 or length-2 positive integer vector c(width, height). Number of tiles in each direction. A scalar n is recycled to c(n, n) for square tiles. Default c(8L, 8L).

Returns

A new Image of the same depth as the input.

Examples

\donttest{
img_path <- system.file("img", "brick_wall.jpg", package = "Retina")
img <- Image$new(img_path)$to_gray()
out <- img$CLAHE(clip_limit = 2.0, tile_grid_size = c(8L, 8L))
out$plot()
}

---

Method CLAHE_()

Apply CLAHE in place. See $CLAHE() for details.

Usage

Image$CLAHE_(clip_limit = 40, tile_grid_size = c(8L, 8L))

Arguments

clip_limit

See $CLAHE().

tile_grid_size

See $CLAHE().

Returns

self invisibly.

Examples

\donttest{
img_path <- system.file("img", "brick_wall.jpg", package = "Retina")
img <- Image$new(img_path)$to_gray()
img$CLAHE_(clip_limit = 2.0, tile_grid_size = c(8L, 8L))
img$plot()
}

---

Method minmax_loc()

Find the minimum and maximum pixel values and their locations in a single-channel image.

Usage

Image$minmax_loc()

Returns

A named list with six elements: min_val (double), min_row (integer), min_col (integer), max_val (double), max_row (integer), max_col (integer). All coordinates are 1-based. When multiple pixels share the minimum or maximum value, the first occurrence in row-major order is returned. For multi-channel images, use split_channels() first.

Examples

\donttest{
img_path <- system.file("img", "brick_wall.jpg", package = "Retina")
img <- Image$new(img_path)$to_gray()
loc <- img$minmax_loc()
cat("Max pixel:", loc$max_val, "at row", loc$max_row, "col", loc$max_col)
}

---

Method count_nonzero()

Count non-zero pixels in a single-channel image.

Usage

Image$count_nonzero()

Returns

A single integer.

Examples

\donttest{
img_path <- system.file("img", "brick_wall.jpg", package = "Retina")
img <- Image$new(img_path)$to_gray()$threshold(128)
n <- img$count_nonzero()
# Multi-channel: split then apply
color_img <- Image$new(img_path)
counts <- lapply(split_channels(color_img), \(ch) ch$count_nonzero())
}

---

Method find_nonzero()

Find the coordinates of all non-zero pixels in a single-channel image.

Usage

Image$find_nonzero()

Returns

A data frame with integer columns row and col (1-based, R matrix convention), ordered in row-major order. Returns a zero-row data frame when no non-zero pixels exist.

Examples

\donttest{
img_path <- system.file("img", "brick_wall.jpg", package = "Retina")
img <- Image$new(img_path)$to_gray()$threshold(128)
coords <- img$find_nonzero()
head(coords)
# Multi-channel: split then apply
color_img <- Image$new(img_path)
all_coords <- lapply(split_channels(color_img), \(ch) ch$find_nonzero())
}

---

Method pow()

Raise every pixel to a power element-wise. The image must be CV_32F or CV_64F — use $convert_depth("CV_32F") first for integer images. A negative pixel raised to a fractional exponent produces NaN.

Usage

Image$pow(power)

Arguments

power

Single finite numeric. The exponent. Negative, zero, and fractional values are accepted.

Returns

A new Image with the same depth and colorspace.

Examples

\donttest{
img32 <- Image$new(array(4.0, dim = c(5L, 5L, 1L)), "GRAY", depth = "CV_32F")
img32$pow(2.0)
}

---

Method pow_()

Raise every pixel to a power, in place.

Usage

Image$pow_(power)

Arguments

power

Single finite numeric. The exponent.

Returns

self invisibly.

---

Method exp()

Apply element-wise natural exponential (\(e^x\)) to every pixel. The image must be CV_32F or CV_64F.

Usage

Image$exp()

Returns

A new Image with the same depth and colorspace.

Examples

\donttest{
img32 <- Image$new(array(1.0, dim = c(5L, 5L, 1L)), "GRAY", depth = "CV_32F")
img32$exp()
}

---

Method exp_()

Apply element-wise natural exponential in place.

Usage

Image$exp_()

Returns

self invisibly.

---

Method log()

Apply element-wise natural logarithm (\(\ln(x)\)) to every pixel. The image must be CV_32F or CV_64F. Pixels \(\le 0\) produce -Inf or NaN — sanitise the image first if this may occur.

Usage

Image$log()

Returns

A new Image with the same depth and colorspace.

Examples

\donttest{
img32 <- Image$new(array(exp(1), dim = c(5L, 5L, 1L)), "GRAY", depth = "CV_32F")
img32$log()
}

---

Method log_()

Apply element-wise natural logarithm in place.

Usage

Image$log_()

Returns

self invisibly.

---

Method sqrt()

Apply element-wise square root to every pixel. The image must be CV_32F or CV_64F. Pixels < 0 produce NaN — sanitise the image first if this may occur.

Usage

Image$sqrt()

Returns

A new Image with the same depth and colorspace.

Examples

\donttest{
img32 <- Image$new(array(9.0, dim = c(5L, 5L, 1L)), "GRAY", depth = "CV_32F")
img32$sqrt()
}

---

Method sqrt_()

Apply element-wise square root in place.

Usage

Image$sqrt_()

Returns

self invisibly.

---

Method extract_channel()

Extract a single channel as a new single-channel Image.

Usage

Image$extract_channel(k)

Arguments

k

Single integer (1-based). Channel index between 1 and nchan.

Returns

A new single-channel Image with colorspace "GRAY".

Examples

\donttest{
img <- Image$new(array(c(rep(10L, 100L), rep(20L, 100L), rep(30L, 100L)),
                       dim = c(10L, 10L, 3L)), "BGR")
img$extract_channel(2L)  # green channel
}

---

Method insert_channel()

Insert a single-channel Image into channel k, returning a new Image.

Usage

Image$insert_channel(ch, k)

Arguments

ch

A single-channel Image with the same depth, nrow, and ncol as self.

k

Single integer (1-based). Channel index between 1 and nchan.

Returns

A new Image with the same colorspace as self.

Examples

\donttest{
img <- Image$new(array(c(rep(10L, 100L), rep(20L, 100L), rep(30L, 100L)),
                       dim = c(10L, 10L, 3L)), "BGR")
new_ch <- Image$new(array(99L, dim = c(10L, 10L, 1L)), "GRAY")
img$insert_channel(new_ch, 2L)
}

---

Method insert_channel_()

Insert a single-channel Image into channel k, in place.

Usage

Image$insert_channel_(ch, k)

Arguments

ch

A single-channel Image with the same depth, nrow, and ncol as self.

k

Single integer (1-based). Channel index between 1 and nchan.

Returns

self invisibly.

Examples

\donttest{
img <- Image$new(array(c(rep(10L, 100L), rep(20L, 100L), rep(30L, 100L)),
                       dim = c(10L, 10L, 3L)), "BGR")
new_ch <- Image$new(array(99L, dim = c(10L, 10L, 1L)), "GRAY")
img$insert_channel_(new_ch, 2L)
}

---

Method LUT()

Apply a lookup table (LUT) to remap pixel values.

Usage

Image$LUT(lut)

Arguments

lut

A numeric vector of length 256 (CV_8U) or 65536 (CV_16U/CV_16S), applied identically to all channels; or a numeric matrix with the same row count and nchan columns — one column per channel applied in channel order. Values must be non-NA, finite, and coercible to integer. Only integer-depth images are supported (CV_8U, CV_16U, CV_16S). For CV_16S sources the LUT index is pixel + 32768: pixel -32768 maps to row 1 (index 0); pixel 0 maps to row 32769.

Returns

A new Image.

Examples

\donttest{
img <- Image$new(array(100L, dim = c(5L, 5L, 1L)), "GRAY")
img$LUT(as.integer(255:0))  # invert
}

---

Method LUT_()

Apply a lookup table in place.

Usage

Image$LUT_(lut)

Arguments

lut

See $LUT().

Returns

self invisibly.

Examples

\donttest{
img <- Image$new(array(100L, dim = c(5L, 5L, 1L)), "GRAY")
img$LUT_(as.integer(255:0))  # invert in place
}

---

Method print()

Print a summary of the image.

Usage

Image$print(...)

Arguments

...

Ignored.

Returns

self invisibly.

Examples

## ------------------------------------------------
## Method `Image$sobel`
## ------------------------------------------------

# \donttest{
img_path <- system.file("img", "brick_wall.jpg", package = "Retina")
img <- Image$new(img_path)
grad_x <- img$sobel(1, 0)
#> ddepth not specified; using "CV_16S" for a CV_8U image.
grad_x$plot()

# }

## ------------------------------------------------
## Method `Image$sobel_`
## ------------------------------------------------

# \donttest{
img_path <- system.file("img", "brick_wall.jpg", package = "Retina")
img <- Image$new(img_path)
img$sobel_(1, 0)
#> ddepth not specified; using "CV_16S" for a CV_8U image.
img$plot()

# }

## ------------------------------------------------
## Method `Image$laplacian`
## ------------------------------------------------

# \donttest{
img_path <- system.file("img", "flower.jpg", package = "Retina")
img <- Image$new(img_path)
edges <- img$laplacian()
#> ddepth not specified; using "CV_16S" for a CV_8U image.
edges$plot()

# }

## ------------------------------------------------
## Method `Image$laplacian_`
## ------------------------------------------------

# \donttest{
img_path <- system.file("img", "flower.jpg", package = "Retina")
img <- Image$new(img_path)
img$laplacian_()
#> ddepth not specified; using "CV_16S" for a CV_8U image.
img$plot()

# }

## ------------------------------------------------
## Method `Image$canny`
## ------------------------------------------------

# \donttest{
img_path <- system.file("img", "staircase.jpg", package = "Retina")
img <- Image$new(img_path)$convert_color("GRAY")
edges <- img$canny(50, 150)
edges$plot()

# }

## ------------------------------------------------
## Method `Image$canny_`
## ------------------------------------------------

# \donttest{
img_path <- system.file("img", "staircase.jpg", package = "Retina")
img <- Image$new(img_path)$convert_color("GRAY")
img$canny_(50, 150)
img$plot()

# }

## ------------------------------------------------
## Method `Image$scharr`
## ------------------------------------------------

# \donttest{
img_path <- system.file("img", "brick_wall.jpg", package = "Retina")
img <- Image$new(img_path)
grad_x <- img$scharr(1, 0)
#> ddepth not specified; using "CV_16S" for a CV_8U image.
grad_x$plot()

# }

## ------------------------------------------------
## Method `Image$scharr_`
## ------------------------------------------------

# \donttest{
img_path <- system.file("img", "brick_wall.jpg", package = "Retina")
img <- Image$new(img_path)
img$scharr_(1, 0)
#> ddepth not specified; using "CV_16S" for a CV_8U image.
img$plot()

# }

## ------------------------------------------------
## Method `Image$filter2D`
## ------------------------------------------------

# \donttest{
img_path <- system.file("img", "flower.jpg", package = "Retina")
img <- Image$new(img_path)
sharpen <- matrix(c(0,-1,0,-1,5,-1,0,-1,0), nrow = 3)
sharpened <- img$filter2D(sharpen)
sharpened$plot()

# }

## ------------------------------------------------
## Method `Image$filter2D_`
## ------------------------------------------------

# \donttest{
img_path <- system.file("img", "flower.jpg", package = "Retina")
img <- Image$new(img_path)
sharpen <- matrix(c(0,-1,0,-1,5,-1,0,-1,0), nrow = 3)
img$filter2D_(sharpen)
img$plot()

# }

## ------------------------------------------------
## Method `Image$sep_filter2D`
## ------------------------------------------------

# \donttest{
img_path <- system.file("img", "flower.jpg", package = "Retina")
img <- Image$new(img_path)
blurred <- img$sep_filter2D(rep(1/3, 3), rep(1/3, 3))
blurred$plot()

# }

## ------------------------------------------------
## Method `Image$sep_filter2D_`
## ------------------------------------------------

# \donttest{
img_path <- system.file("img", "flower.jpg", package = "Retina")
img <- Image$new(img_path)
img$sep_filter2D_(rep(1/3, 3), rep(1/3, 3))
img$plot()

# }

## ------------------------------------------------
## Method `Image$morph`
## ------------------------------------------------

# \donttest{
img_path <- system.file("img", "flower.jpg", package = "Retina")
img <- Image$new(img_path)$convert_color("GRAY")
eroded <- img$morph("erode")
eroded$plot()

# }

## ------------------------------------------------
## Method `Image$morph_`
## ------------------------------------------------

# \donttest{
img_path <- system.file("img", "flower.jpg", package = "Retina")
img <- Image$new(img_path)$convert_color("GRAY")
img$morph_("erode")
img$plot()

# }

## ------------------------------------------------
## Method `Image$resize`
## ------------------------------------------------

# \donttest{
img_path <- system.file("img", "flower.jpg", package = "Retina")
img <- Image$new(img_path)
img$resize(width = 320L, height = 240L)$plot()

img$resize(fx = 0.5, fy = 0.5)$plot()

# }

## ------------------------------------------------
## Method `Image$resize_`
## ------------------------------------------------

# \donttest{
img_path <- system.file("img", "flower.jpg", package = "Retina")
img <- Image$new(img_path)
img$resize_(fx = 0.5, fy = 0.5)
img$plot()

# }

## ------------------------------------------------
## Method `Image$rotate`
## ------------------------------------------------

# \donttest{
img_path <- system.file("img", "flower.jpg", package = "Retina")
img <- Image$new(img_path)
img$rotate(45)$plot()

# }

## ------------------------------------------------
## Method `Image$rotate_`
## ------------------------------------------------

# \donttest{
img_path <- system.file("img", "flower.jpg", package = "Retina")
img <- Image$new(img_path)
img$rotate_(45)
img$plot()

# }

## ------------------------------------------------
## Method `Image$flip`
## ------------------------------------------------

# \donttest{
img_path <- system.file("img", "flower.jpg", package = "Retina")
img <- Image$new(img_path)
img$flip(flip_h = TRUE)$plot()

# }

## ------------------------------------------------
## Method `Image$flip_`
## ------------------------------------------------

# \donttest{
img_path <- system.file("img", "flower.jpg", package = "Retina")
img <- Image$new(img_path)
img$flip_(flip_v = TRUE)
img$plot()

# }

## ------------------------------------------------
## Method `Image$crop`
## ------------------------------------------------

# \donttest{
img_path <- system.file("img", "flower.jpg", package = "Retina")
img <- Image$new(img_path)
img$crop(1L, 1L, 100L, 100L)$plot()

# }

## ------------------------------------------------
## Method `Image$crop_`
## ------------------------------------------------

# \donttest{
img_path <- system.file("img", "flower.jpg", package = "Retina")
img <- Image$new(img_path)
img$crop_(1L, 1L, 100L, 100L)
img$plot()

# }

## ------------------------------------------------
## Method `Image$warp_affine`
## ------------------------------------------------

# \donttest{
img_path <- system.file("img", "flower.jpg", package = "Retina")
img <- Image$new(img_path)
m <- affine_translate(50, 30)
img$warp_affine(m)$plot()

# }

## ------------------------------------------------
## Method `Image$warp_affine_`
## ------------------------------------------------

# \donttest{
img_path <- system.file("img", "flower.jpg", package = "Retina")
img <- Image$new(img_path)
img$warp_affine_(affine_translate(50, 30))
img$plot()

# }

## ------------------------------------------------
## Method `Image$warp_perspective`
## ------------------------------------------------

# \donttest{
img_path <- system.file("img", "flower.jpg", package = "Retina")
img <- Image$new(img_path)
w <- img$ncol; h <- img$nrow
src <- matrix(c(1, 1,  w, 1,  w, h,  1, h), nrow = 4, byrow = TRUE)
dst <- matrix(c(round(w*0.1), 1,  w, 1,  w, h,  1, h), nrow = 4, byrow = TRUE)
m <- perspective_from_points(src, dst)
img$warp_perspective(m)$plot()

# }

## ------------------------------------------------
## Method `Image$warp_perspective_`
## ------------------------------------------------

# \donttest{
img_path <- system.file("img", "flower.jpg", package = "Retina")
img <- Image$new(img_path)
w <- img$ncol; h <- img$nrow
src <- matrix(c(1, 1,  w, 1,  w, h,  1, h), nrow = 4, byrow = TRUE)
dst <- matrix(c(round(w*0.1), 1,  w, 1,  w, h,  1, h), nrow = 4, byrow = TRUE)
img$warp_perspective_(perspective_from_points(src, dst))
img$plot()

# }

## ------------------------------------------------
## Method `Image$draw_line`
## ------------------------------------------------

# \donttest{
img_path <- system.file("img", "flower.jpg", package = "Retina")
img <- Image$new(img_path)
img$draw_line(1, 1, 100, 100, color = "red")$plot()

# }

## ------------------------------------------------
## Method `Image$draw_arrow`
## ------------------------------------------------

# \donttest{
img_path <- system.file("img", "flower.jpg", package = "Retina")
img <- Image$new(img_path)
img$draw_arrow(10, 10, 100, 100, color = "blue")$plot()

# }

## ------------------------------------------------
## Method `Image$draw_rectangle`
## ------------------------------------------------

# \donttest{
img_path <- system.file("img", "flower.jpg", package = "Retina")
img <- Image$new(img_path)
img$draw_rectangle(10, 10, 100, 100, color = "blue", filled = TRUE)$plot()

# }

## ------------------------------------------------
## Method `Image$draw_circle`
## ------------------------------------------------

# \donttest{
img_path <- system.file("img", "flower.jpg", package = "Retina")
img <- Image$new(img_path)
img$draw_circle(100, 100, 50, color = "green", filled = TRUE)$plot()

# }

## ------------------------------------------------
## Method `Image$draw_ellipse`
## ------------------------------------------------

# \donttest{
img_path <- system.file("img", "flower.jpg", package = "Retina")
img <- Image$new(img_path)
img$draw_ellipse(100, 100, 80L, 40L, angle = 30, color = "red")$plot()

# }

## ------------------------------------------------
## Method `Image$draw_arc`
## ------------------------------------------------

# \donttest{
img_path <- system.file("img", "flower.jpg", package = "Retina")
img <- Image$new(img_path)
img$draw_arc(100, 100, 80L, 40L, start_angle = 0, end_angle = 180,
             color = "red")$plot()

# }

## ------------------------------------------------
## Method `Image$draw_polyline`
## ------------------------------------------------

# \donttest{
img_path <- system.file("img", "flower.jpg", package = "Retina")
img <- Image$new(img_path)
pts <- matrix(c(10, 10, 100, 10, 55, 90), nrow = 3, ncol = 2, byrow = TRUE)
img$draw_polyline(pts, closed = TRUE, color = "yellow")$plot()

# }

## ------------------------------------------------
## Method `Image$fill_poly`
## ------------------------------------------------

# \donttest{
img_path <- system.file("img", "flower.jpg", package = "Retina")
img <- Image$new(img_path)
pts <- matrix(c(10, 10, 100, 10, 55, 90), nrow = 3, ncol = 2, byrow = TRUE)
img$fill_poly(pts, color = "cyan")$plot()

# }

## ------------------------------------------------
## Method `Image$draw_text`
## ------------------------------------------------

# \donttest{
img_path <- system.file("img", "flower.jpg", package = "Retina")
img <- Image$new(img_path)
img$draw_text("Hello", 10, 50, font = "duplex", font_size = 1.5,
              color = "white")$plot()

# }

## ------------------------------------------------
## Method `Image$hist`
## ------------------------------------------------

# \donttest{
img_path <- system.file("img", "flower.jpg", package = "Retina")
img <- Image$new(img_path)$to_gray()
h <- img$hist(bins = 256L, range = c(0, 256))
# plot with ggplot2:
# ggplot2::ggplot(h, ggplot2::aes(x = bin_center, y = count)) +
#   ggplot2::geom_col()
# }

## ------------------------------------------------
## Method `Image$hist_eq`
## ------------------------------------------------

# \donttest{
img_path <- system.file("img", "brick_wall.jpg", package = "Retina")
img <- Image$new(img_path)$to_gray()
eq  <- img$hist_eq()
eq$plot()

# }

## ------------------------------------------------
## Method `Image$hist_eq_`
## ------------------------------------------------

# \donttest{
img_path <- system.file("img", "brick_wall.jpg", package = "Retina")
img <- Image$new(img_path)$to_gray()
img$hist_eq_()
img$plot()

# }

## ------------------------------------------------
## Method `Image$hist_match`
## ------------------------------------------------

# \donttest{
img_path <- system.file("img", "brick_wall.jpg", package = "Retina")
ref_path <- system.file("img", "flower.jpg",     package = "Retina")
src <- Image$new(img_path)$to_gray()
ref <- Image$new(ref_path)$to_gray()
ref_hist <- ref$hist(bins = 256L, range = c(0, 255))
out <- src$hist_match(ref_hist)
out$plot()

# }

## ------------------------------------------------
## Method `Image$hist_match_`
## ------------------------------------------------

# \donttest{
img_path <- system.file("img", "brick_wall.jpg", package = "Retina")
ref_path <- system.file("img", "flower.jpg",     package = "Retina")
src <- Image$new(img_path)$to_gray()
ref <- Image$new(ref_path)$to_gray()
ref_hist <- ref$hist(bins = 256L, range = c(0, 256))
src$hist_match_(ref_hist)
src$plot()

# }

## ------------------------------------------------
## Method `Image$CLAHE`
## ------------------------------------------------

# \donttest{
img_path <- system.file("img", "brick_wall.jpg", package = "Retina")
img <- Image$new(img_path)$to_gray()
out <- img$CLAHE(clip_limit = 2.0, tile_grid_size = c(8L, 8L))
out$plot()

# }

## ------------------------------------------------
## Method `Image$CLAHE_`
## ------------------------------------------------

# \donttest{
img_path <- system.file("img", "brick_wall.jpg", package = "Retina")
img <- Image$new(img_path)$to_gray()
img$CLAHE_(clip_limit = 2.0, tile_grid_size = c(8L, 8L))
img$plot()

# }

## ------------------------------------------------
## Method `Image$minmax_loc`
## ------------------------------------------------

# \donttest{
img_path <- system.file("img", "brick_wall.jpg", package = "Retina")
img <- Image$new(img_path)$to_gray()
loc <- img$minmax_loc()
cat("Max pixel:", loc$max_val, "at row", loc$max_row, "col", loc$max_col)
#> Max pixel: 255 at row 10 col 350
# }

## ------------------------------------------------
## Method `Image$count_nonzero`
## ------------------------------------------------

# \donttest{
img_path <- system.file("img", "brick_wall.jpg", package = "Retina")
img <- Image$new(img_path)$to_gray()$threshold(128)
n <- img$count_nonzero()
# Multi-channel: split then apply
color_img <- Image$new(img_path)
counts <- lapply(split_channels(color_img), \(ch) ch$count_nonzero())
# }

## ------------------------------------------------
## Method `Image$find_nonzero`
## ------------------------------------------------

# \donttest{
img_path <- system.file("img", "brick_wall.jpg", package = "Retina")
img <- Image$new(img_path)$to_gray()$threshold(128)
coords <- img$find_nonzero()
head(coords)
#>   row col
#> 1   1   1
#> 2   1   2
#> 3   1   3
#> 4   1   4
#> 5   1   5
#> 6   1   6
# Multi-channel: split then apply
color_img <- Image$new(img_path)
all_coords <- lapply(split_channels(color_img), \(ch) ch$find_nonzero())
# }

## ------------------------------------------------
## Method `Image$pow`
## ------------------------------------------------

# \donttest{
img32 <- Image$new(array(4.0, dim = c(5L, 5L, 1L)), "GRAY", depth = "CV_32F")
img32$pow(2.0)
#> <Image>
#>   Size      : 5 x 5
#>   Channels  : 1
#>   Depth     : CV_32F
#>   Colorspace: GRAY
#>   GPU       : FALSE
# }

## ------------------------------------------------
## Method `Image$exp`
## ------------------------------------------------

# \donttest{
img32 <- Image$new(array(1.0, dim = c(5L, 5L, 1L)), "GRAY", depth = "CV_32F")
img32$exp()
#> <Image>
#>   Size      : 5 x 5
#>   Channels  : 1
#>   Depth     : CV_32F
#>   Colorspace: GRAY
#>   GPU       : FALSE
# }

## ------------------------------------------------
## Method `Image$log`
## ------------------------------------------------

# \donttest{
img32 <- Image$new(array(exp(1), dim = c(5L, 5L, 1L)), "GRAY", depth = "CV_32F")
img32$log()
#> <Image>
#>   Size      : 5 x 5
#>   Channels  : 1
#>   Depth     : CV_32F
#>   Colorspace: GRAY
#>   GPU       : FALSE
# }

## ------------------------------------------------
## Method `Image$sqrt`
## ------------------------------------------------

# \donttest{
img32 <- Image$new(array(9.0, dim = c(5L, 5L, 1L)), "GRAY", depth = "CV_32F")
img32$sqrt()
#> <Image>
#>   Size      : 5 x 5
#>   Channels  : 1
#>   Depth     : CV_32F
#>   Colorspace: GRAY
#>   GPU       : FALSE
# }

## ------------------------------------------------
## Method `Image$extract_channel`
## ------------------------------------------------

# \donttest{
img <- Image$new(array(c(rep(10L, 100L), rep(20L, 100L), rep(30L, 100L)),
                       dim = c(10L, 10L, 3L)), "BGR")
#> Depth not specified. Defaulting to CV_8U.
img$extract_channel(2L)  # green channel
#> <Image>
#>   Size      : 10 x 10
#>   Channels  : 1
#>   Depth     : CV_8U
#>   Colorspace: GRAY
#>   GPU       : FALSE
# }

## ------------------------------------------------
## Method `Image$insert_channel`
## ------------------------------------------------

# \donttest{
img <- Image$new(array(c(rep(10L, 100L), rep(20L, 100L), rep(30L, 100L)),
                       dim = c(10L, 10L, 3L)), "BGR")
#> Depth not specified. Defaulting to CV_8U.
new_ch <- Image$new(array(99L, dim = c(10L, 10L, 1L)), "GRAY")
#> Depth not specified. Defaulting to CV_8U.
img$insert_channel(new_ch, 2L)
#> <Image>
#>   Size      : 10 x 10
#>   Channels  : 3
#>   Depth     : CV_8U
#>   Colorspace: BGR
#>   GPU       : FALSE
# }

## ------------------------------------------------
## Method `Image$insert_channel_`
## ------------------------------------------------

# \donttest{
img <- Image$new(array(c(rep(10L, 100L), rep(20L, 100L), rep(30L, 100L)),
                       dim = c(10L, 10L, 3L)), "BGR")
#> Depth not specified. Defaulting to CV_8U.
new_ch <- Image$new(array(99L, dim = c(10L, 10L, 1L)), "GRAY")
#> Depth not specified. Defaulting to CV_8U.
img$insert_channel_(new_ch, 2L)
# }

## ------------------------------------------------
## Method `Image$LUT`
## ------------------------------------------------

# \donttest{
img <- Image$new(array(100L, dim = c(5L, 5L, 1L)), "GRAY")
#> Depth not specified. Defaulting to CV_8U.
img$LUT(as.integer(255:0))  # invert
#> <Image>
#>   Size      : 5 x 5
#>   Channels  : 1
#>   Depth     : CV_8U
#>   Colorspace: GRAY
#>   GPU       : FALSE
# }

## ------------------------------------------------
## Method `Image$LUT_`
## ------------------------------------------------

# \donttest{
img <- Image$new(array(100L, dim = c(5L, 5L, 1L)), "GRAY")
#> Depth not specified. Defaulting to CV_8U.
img$LUT_(as.integer(255:0))  # invert in place
# }
